50dB high transparent RFI and electric field screening fabric Shield
 |
Very transparent RF screening solution for windows, clothes, screening tents, medical applications with very high damping up to 50dB (99,999%). It is made from a patented high-tech shielding-fibre. Highly transparent, washable, antiseptic rf-shielding. Optimal for usage as Rf window protection, fly screens, curtains, rf protective clothing, screening tents etc. Protects against any kind of rf “electrosmog” just like A2000+, but offers a 1000 fold better shielding-performance and protection especially in the high GHz range (mobile phones, microwaves, aviation radar, military broadcast, etc.). This product probably by far offers the world’s best rf-shielding-performance among the highly transparent screening fabrics. Also effective for low frequency electric fields caused by power lines, power cables, etc. if grounded with our optional grounding kit. Very easy handling even for the amateur. Shielding properties RF Fields: 43dB (99,99%) to 50dB (99,999%) Low Frequency Electric Fields: 99,99% to 99,999% (only with optional grounding kit) Static Electric Fields: 99,99% to 99,999 (only with optional grounding kit) |
| Application examples:
Examples for possible radiating sources within frequency range (100MHz – 18GHz) which can be screened:
|
|
| Technical characteristics: | |
| Shielding | RF & LF electric fields |
| Frequency range | 100 MHz to 18 GHz |
| Damping (dB) | 50 dB |
| Damping (%) | 99,999 |
| Screening material | Silver |
| Carrier material | Polyamide |
| Color | silver |
| Width | 1,4 m |
| Thickness | 0,1 mm |
| Available Length | multiple of 1 m² |
| Mesh size | approx. 0.7 mm |
| Weight | approx. 15 g/m² |
| Included in delivery | Shield, size according to your order |
| Short English manual | |
| Additional accessories (optional) | Grounding Kit |
| Product documentation and software: | |
| Data sheet | Data sheet |
